Manufacturer: WAM Model: WBH550 Type: Ploughshare mixer Total volume: 550L Capacity: 155 – 385 L Material: stainless steel Main motor power: 9.2 kW ATEX tulip-shaped chopper: 3 kW Bearing seal: air purge Filter support Bag emptying hopper Drain valve: pneumatic Secondary drain valve: manual Electrical cabinet with speed variation Dismantled platform available with equipment including: mixer support, platform, and stairs.
Manufacturer : Lodige Model : M20 GRE Year : 1972 Type: ploughshare mixer for powders Total volume : 20 Litres Motor : 1,1 KW Video available in operation Static counter blade Transmission and sealing: reconditioned Mixing chamber rotation Bin: filling / emptying
Manufacturer : Lodige Model : M50G Year : 1967 Type: ploughshare mixer for powders Total volume: 50 Litres AEG 1.5 KW motor Video available in operation Transmission and sealing: reconditioned Mixing chamber rotation Bin: filling / emptying
Old Lodige KM 1200 D continuous mixer with ploughshares (year 1977) transformed into a mixer-dryer (year 2017) by the previous user. Modification made : New enclosure / mixing chamber in stainless steel 316. Change of motor transmission: belt -> geared motor Main material: 316 stainless steel Year: 2017 Type of drying: hot air blowing Without electrical cabinet With piping 1
Manufacturer : Loedige Model: FM 130D 1Z Year : 1964 Type : Ploughshare mixer Product contact material : stainless steel Capacity : 135L Jacketed : 12 L Maximum temperature : 158°C Motor power : 4 kW Chopper : 4 KW Remote electrical cabinet Seal: air purge system Drain valve: manual Functional equipment: video available on request Option no. 1
Manufacturer: WAM Model: WBHVX 300 PO Year : 2006 Type : ploughshare mixer Materials : stainless steel Volume : 300L Spray nozzle Separate control cabinet Access platform Chopper: 4 KW Main motor: 11 KW Speed: 141 rpm Variable speed drive Seal: air purge system Drain valve: pneumatic Video available
Manufacturer: Loedige Model: FM130D Year: – Type: turbo powder mixer / ploughshare mixer for pilot production. external material : normal steel inside material: stainless steel Capacity : 130 L Feed: hopper with manual butterfly valve Emptying : manual butterfly valve Chopper : side knives Electrical cabinet Transmission : belts
Type : mixer with ploughshares / turbo powder mixer Manufacturer: MAP (WAM division) Material: steel Access : 2 central doors Emptying: pneumatic cylinder Total volume : 1200 L Motor power : 22 KW Atex classification : Ex II 3 D T5 Speed : 112 trs / min Easy replacement / change of mixing tools (shares, blades, …) Electrical cabinet: yes
Manufacturer: Lödige Model: FM 300 D / 1ZF Year: 1979 Total capacity: 300 L Material in contact with the product: stainless steel Input for 1 x chopper Sold without chopper’s tools (motor + knives) Motor : Siemens 11A3163 6AA20 Power: 7,5 KW Transmission: 3 belts Manual drain valve Safety sensor for open/closed valve (to be connected)
Type : mixer with ploughshares Manufacturer: MAP (WAM division) Material: normal steel Easy access: full opening Emptying: pneumatic valve Useful volume: 770 L Motor power: 22 KW Easy replacement / change of mixing tools (shares, blades, …) Electrical cabinet: yes Use: Mixing of solid products (powders,…) / Treatment of dry products with liquid spray
Mixer Lödige FKM 2000 D for powder Volume : 2000 L Construction EExe II Mirror polished stainless steel Pharmaceutical environment Airtightness / purge by air. Injection, spray nozzle x3 in front of each lump breakers Anti-deposit ploughshare blades. Manual outlet hatch Inspection hatch with handle x 2 + magnetic lock Siemens engine : – Power 75 KW – Speed: 1500
